Singer XL-5000 - Page 31

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387809
KNEE LIFTER INSERT (ASM.)
1
2
*
387823
KNEE LIFTER PAD
(1)
3
387814
WASHER
1
4
387810
KNEE LIFTER CONNECTING SHAFT (ASM.)
1
5
387811
SPRING
1
6
283486
SCREW
1
7
387417
WASHER
1
8
387812
SPRING
1
9
387813
KNEE LIFTER LINK PLATE (TOTAL ASM.)
1
10
283502
SCREW
2
11
387815
KNEE LIFTER LINK
1
12
387816
KNEE LIFTER LINK ARM A
1
13
387817
KNEE LIFTER LINK ARM B (ASM.)
1
14
387818
FULCRUM SHAFT
1
15
387142
SCREW
1
16
283461
E RING
1
17
387422
WASHER
1
18
387820
SPRING
1
19
387819
SPRING HOOK
1
20
283502
SCREW
1
21
387821
KNEE LIFTER RELEASE PLATE (ASM.)
1
22
387822
KNEE LIFTER RELEASE LINK (ASM.)
1
23
283459
E RING
1
24
386118
ECCENTRIC COLLAR
1
25
386520
SCREW
2
26
283471
SCREW
1
