REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387359
POWER TRANSFORMER BOX (ASM.)(120V)
1
2
388094
POWER TRANSFORMER BOX (ASM.)(230V)
1
3
387876
INLET COVER
(1)
4
283523
SCREW
(1)
5
283355
BAND
(1)
6
387877
FILTER BOARD (TOTAL ASM.)(120V)
(1)
7
388092
FILTER BOARD (TOTAL ASM.)(230V)
(1)
8
386477
FUSE 5A (120V)
(1)
9
388093
FUSE 3.15A (230V)
(1)
10
387875
POWER TRANSFORMER BOX
(1)
11
387360
ELECTRIC POWER BOARD (TOTAL ASM.)
1
12
387879
INSULATING SHEET
(1)
13
387873
INVERTER CONNECTING LEAD WIRE (ASM.)
(1)
14
387881
POWER SUPPLY CONNECTING CABLE (ASM.)
(1)
15
387883
ELECTRIC POWER BOARD CONNECTING CABLE (ASM.)
(1)
16
387878
ELECTRIC POWER BOARD (ASM.)
(1)
17
387376
TIME-LAG FUSE 5A
(1)
18
386478
FUSE (3.15A) (120/230V)
(2)
19
388009
MAIN MOTOR (TOTAL ASM.)
1
20
388008
MAIN MOTOR (ASM.)
(1)
21
387384
MAIN MOTOR PIN
(2)
22
388012
MOTOR SHAFT PULLEY
(1)
23
388013
FLANGE
(1)
24
387699
E RING
(1)
25
388015
MP SHIELD PLATE
(1)
26
388016
MP BOARD BRACKET
(1)
27
388021
MAIN MOTOR FIXING PLATE
(1)
28
283476
SCREW
(2)
29
283522
SCREW
(2)
30
388018
MOTOR BELT GUIDE
(1)
31
283470
SCREW
(1)
32
388022
MP DETECTING BOARD (ASM.)
(1)
33
283522
SCREW
(1)
34
388020
THERMISTOR (ASM.)
(1)
35
283470
SCREW
(1)
36
387006
BAND (SMALL)
1
37
283502
SCREW
2
38
387361
MICRO COMPUTER CIRCUIT BOARD (ASM.)
1
39
283502
SCREW
4
40
387880
BAND
1
41
387880
BAND
1
42
387880
BAND
2
43
283355
BAND
1
44
283322
CORD HOLDER
1
45
388019
MOTOR TIMING BELT
1
46
283502
SCREW
3
47
387886
SERIAL COMMUNICATION RELAY CORD (TOTAL ASM.)
1
48
387885
SERIAL COMMUNICATION RELAY CORD (ASM.)
(1)
49
387884
CONNECTOR FIXING PLATE
(1)
50
283355
BAND
(1)
51
283502
SCREW
2
52
387887
ELECTRIC POWER BOX (ASM.)(120V)
1
53
388091
POWER TRANSFORMER (ASM.)(230V)
1
54
283502
SCREW
3
