Singer XL-5000 - Page 35

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
383885
THREAD CHANGER (COMPLETE SET)
1
2
387940
THREAD CHANGER BASE PLATE (ASM.)
(1)
3
387942
THREAD CHANGER CHANGE-OVER ARM (TOTAL ASM.)
(1)
4
387941
THREAD CHANGER CHANGE-OVER ARM (ASM.)
(1)
5
387943
WORKING PLATE (RIGHT) (ASM.)
(1)
6
387944
WORKING PLATE (LEFT) (ASM.)
(1)
7
387945
SPRING (RIGHT)
(1)
8
387946
SPRING (LEFT)
(1)
9
283459
E RING
(2)
10
387416
WASHER
(1)
11
387947
WORKING SHAFT
(1)
12
387948
SPRING
(1)
13
283459
E RING
(2)
14
283491
SCREW
(4)
15
387950
LATCH (ASM.)
(1)
16
387949
LATCH
(1)
17
387951
LATCH KNOB
(1)
18
387952
LATCH SPRING
(1)
19
283459
E RING
(1)
20
387953
WINDING WORM
(1)
21
387954
WINDING WORM SLIDE
(1)
22
387955
SPRING
(1)
23
283459
E RING
(1)
24
387388
E RING
(1)
25
387957
THREAD CHANGER BODY (PARTIAL ASM.)
(2)
26
*
387956
THREAD CHANGER BODY
(2)
27
*
387958
BAIL
(2)
28
*
387959
BAIL STOPPER B
(2)
29
*
387960
BAIL FULCRUM
(2)
30
*
387961
BAIL STOPPER A
(2)
31
*
387962
BAIL FULCRUM SHAFT
(2)
32
387387
E RING
(2)
33
387963
BAIL WORKING PLATE
(2)
34
387966
THREAD STAND ROD SHAFT (TOTAL ASM.)
(2)
35
387965
THREAD STAND ROD SHAFT (ASM.)
(2)
36
387964
THREAD STAND ROD SHAFT
(2)
37
387967
THREAD SPOOL PRESSER SPRING
(2)
38
283461
E RING
(2)
39
387968
THREAD SPOOL SUPPORT
(2)
40
387969
SPRING
(2)
41
387421
WASHER
(2)
42
283461
E RING
(2)
43
387970
THREAD CHANGER SLIDE BODY
(2)
44
387971
SPRING
(2)
45
387972
THREAD CHANGER GEAR
(2)
46
387973
BEARING
(2)
47
387974
INTERLOCK BELT
(1)
48
283506
SCREW
(2)
49
283486
SCREW
(4)
50
283488
SCREW
(2)
51
387976
THREAD CHANGER COVER (REAR) (PARTIAL ASM.)
(1)
52
387975
THREAD CHANGER COVER (REAR)
(1)
53
387985
FELT
(4)
54
387978
THREAD CHANGER COVER (FRONT) (PARTIAL ASM.)
(2)
55
387977
THREAD CHANGER COVER (FRONT)
(1)
56
387985
FELT
(4)
57
383882
THREAD CHANGER COVER RUBBER
(2)
58
283522
SCREW
(4)
59
387981
THREAD GUIDE PLATE (TOTAL ASM.)
(1)
60
*
387980
THREAD GUIDE PLATE (ASM.)
(1)
61
*
387982
THREAD GUIDE TENSION PLATE
(2)
62
*
387983
SPRING
(2)
63
*
387984
THREAD GUIDE PLATE COVER
(1)
64
*
387151
WASHER
(2)
65
*
283458
E RING
(2)
66
*
385340
SCREW
(1)
67
*
387986
THREAD GUIDE PLATE A
(1)
68
*
283491
SCREW
(1)
69
*
387979
THREAD GUIDE ROD (ASM.)
(1)
70
387987
BOBBIN WINDER PATCH SEAT
(2)
71
387988
BOBBIN WINDER PATCH SEAT (SMALL)
(2)
72
387989
THREAD SPOOL DETENT A
(2)
73
387990
BOBBIN WINDER PATCH SEAT (MEDIUM)
(2)
74
388161
THREAD CHANGER COVER A SEAL
(1)
