Singer XL-5000 - Page 43

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387907
TOP COVER (ASM.)
1
2
387921
EMBROIDERING UNIT HANDLING CAUTION SEAL
(1)
3
387916
DUST-PROOF SEAT A
(2)
4
387909
SIDE COVER (ASM.)
1
5
387917
DUST-PROOF SHEET B
(2)
6
386520
SCREW
2
7
283451
NUT
1
8
387154
SCREW
2
9
387908
BOTTOM COVER
1
10
387440
RUBBER SEAT
2
11
387918
CHANGE-OVER LEVER (ASM.)
1
12
386530
WASHER
1
13
283522
SCREW
1
14
387920
CHANGE-OVER KNOB
1
15
387919
CHANGE-OVER LEVER HOOK
1
16
386420
HOOK SHAFT
1
17
386421
HOOK SPRING
1
18
283522
SCREW
2
19
387923
TRIGGER PIN
1
20
387924
TRIGGER PIN SPRING
1
21
283460
E RING
1
22
283528
WASHER
1
23
387925
TRIGGER LIMIT PLATE
1
24
387926
FULCRUM SHAFT
1
25
387927
RETURN SPRING
1
26
387389
E RING
2
27
387299
MODE CHANGE-OVER CONTACT
1
28
387300
MODE CHANGE-OVER SW PLATE FIXING PLATE
1
29
387929
MODE CHANGE-OVER SWITCH (ASM.)
1
30
283485
SCREW
1
31
387302
NUT
1
32
283522
SCREW
2
33
283335
START SWITCH LEAD TAPE
1
34
283322
CORD HOLDER
1
35
283522
SCREW
1
36
387362
CONNECTING SLIDER A (TOTAL ASM.)
1
37
387911
CONNECTING SLIDER A
(1)
38
387930
DRIVER CABLE (TOTAL ASM.)
(1)
39
387412
SCREW
(2)
40
387006
BAND (SMALL)
(1)
41
387928
SLIDER COVER
1
42
386528
SCREW
2
43
387418
WASHER
2
44
386528
SCREW
2
45
387912
CONNECTING SLIDER B (ASM.)
1
46
387922
EMBROIDERY RELEASE SWITCH (ASM.)
(1)
47
283485
SCREW
(1)
48
387302
NUT
(1)
49
387006
BAND (SMALL)
(1)
50
387913
SLIDER SPRING
2
51
283460
E RING
2
52
387914
SLIDER FULCRUM PLATE
1
53
387410
SCREW
2
54
387915
SLIDER WORKING PLATE (ASM.)
1
55
387154
SCREW
5
- 40 -
