Singer XL-5000 - Page 45

REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387304
Y COORDINATE DRIVE SHAFT
1
2
387081
FELT A
1
3
387405
SCREW
2
4
387900
Y COORDINATE DRIVE PLATE
1
5
387363
Y AXIS DETECTING SWITCH (ASM.)
1
6
387302
NUT
1
7
283485
SCREW
1
8
387902
Y AXIS BELT FIXING PLATE
1
9
387898
Y AXIS INTERMEDIATE PULLEY BRACKET (ASM.)
1
10
385352
WASHER
1
11
387897
Y AXIS INTERMEDIATE PULLEY
1
12
387314
PULLEY FLANGE
1
13
283460
E RING
1
14
387135
SCREW
1
15
387899
Y AXIS FOLLOWER GEAR BRACKET (ASM.)
1
16
385352
WASHER
1
17
387890
Y AXIS FOLLOWER GEAR
1
18
283460
E RING
1
19
387135
SCREW
1
20
387901
Y COORDINATE DRIVE BELT B
1
21
387092
Y COORDINATE DRIVE BELT A
1
22
283470
SCREW
3
23
387311
Y COORDINATE PULLEY (ASM.)
1
24
387135
SCREW
1
25
387904
FRAME HOLDER (ASM.)
1
26
387896
Y COORDINATE BELT HOLDER
1
27
386493
SCREW
1
28
387906
FRME FIXING SPRING
1
29
283491
SCREW
2
30
387098
EMBROIDERY FRAME CLAMP SPRING
1
31
283469
SCREW
1
32
387099
EMBROIDERY FRAME POSITIONING COLLAR
1
33
387133
SCREW
1
34
387905
EMBROIDERY FRAME DETECTING SWITCH GUIDE
1
35
283469
SCREW
1
36
387364
EMBROIDERY FRAME DETECTING SWITCH BOARD (ASM.)
1
37
387391
SCREW
4
38
387006
BAND (SMALL)
4
39
387100
EMBROIDERY FRAME DETECTING LEAD COVER
1
40
386508
SCREW
1
41
387910
FRAME HOLDER COVER
1
42
283522
SCREW
1
- 42 -
