REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387903
MAIN FRAME (ASM.)
1
2
387106
X MOTOR BRACKET (ASM.)
1
3
387365
X AXIS STM
1
4
387108
X MOTOR GEAR
1
5
386522
SCREW
2
6
386493
SCREW
2
7
386377
INTERMEDIATE GEAR A
1
8
283459
E RING
1
9
283497
SCREW
3
10
283474
SCREW
1
11
387313
X COORDINATE SUBORDINATE DRIVE GEAR
1
12
387314
PULLEY FLANGE
1
13
283460
E RING
1
14
387110
X DRIVE BELT
1
15
387315
X PULLEY (ASM.)
1
16
283474
SCREW
1
17
387891
X COORDINATE DRIVE SHAFT
1
18
387114
X COORDINATE DRIVE SHAFT FELT B
1
19
387135
SCREW
2
20
387115
BELT PRESSER A
1
21
387116
BELT PRESSER B
1
22
387136
SCREW
2
23
283523
SCREW
1
24
283322
CORD HOLDER
1
25
387366
X AXIS DETECTING SWITCH (ASM.)
1
26
387302
NUT
1
27
283485
SCREW
1
28
387135
SCREW
1
29
387142
SCREW
1
30
387895
X COORDINATE DRIVE PLATE (ASM.)
1
31
*
387894
X COORDINATE DRIVE PLATE
(1)
32
*
387892
X COORDINATE DRIVE BEARING A
(2)
34
*
387120
X DRIVE SHAFT RECEPTACLE HOLDER
(2)
33
283469
SCREW
(2)
35
283335
START SWITCH LEAD TAPE
1
36
387367
Y AXIS STM
1
37
387122
Y MOTOR GEAR
1
38
386522
SCREW
2
39
386493
SCREW
2
40
387123
CORD HOLDER PLATE
1
41
386609
SCREW
2
- 44 -
