REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387932
LARGE SIZE EMBROIDERY FRAME (ASM.)
1
2
387934
LARGE SIZE EMBROIDERY INNER FRAME (ASM.)
(1)
3
*
387933
LARGE SIZE EMBROIDERY INNER FRAME
(1)
4
*
387935
LARGE SIZE EMBROIDERY INNER FRAME RUBBER
(1)
5
387931
LARGE SIZE EMBROIDERY OUTER FRAME (ASM.)
(1)
6
387126
KNOB SCREW
(1)
7
387128
NUT
(1)
8
387150
WASHER
(1)
9
387127
FRAME RELEASE SPRING
(1)
10
387937
MEDIUM SIZE EMBROIDERY FRAME (ASM.)
1
11
387936
MEDIUM SIZE EMBROIDERY OUTER FRAME (ASM.)
(1)
12
387127
FRAME RELEASE SPRING
(1)
13
387126
KNOB SCREW
(1)
14
387128
NUT
(1)
15
387150
WASHER
(1)
16
387131
MEDIUM SIZE EMBROIDERY INNER FRAME
(1)
17
387938
SMALL SIZE EMBROIDERY FRAME (ASM.)
1
18
388182
CONVERSION TOOL
1
19
388006
CONTINUOUS EMBROIDERY FRAME COMPLETE
1
20
387377
CONTINUOUS EMBROIDERY FRAME BOX
(2)
21
387374
CONTINUOUS EMBROIDERY CARD
(1)
22
388007
CONTINUOUS EMBROIDERY FRAME BASE PLATE (TOTAL ASM.)
(1)
- 46 -
