Singer XL-5000 - Page 5

REF
NO.
NOTE
PART NO.
PART D E S C R I P T I O N
Qty
1
387393
SCREW
2
2
387425
FACE PLATE COVER (ASM.)
1
3
387335
DF KNOB
(1)
4
#1
DF KNOB SPRING
(1)
5
#1
SCREW
(1)
6
#1
FREE ARM UNDER SIDE COVER
(1)
7
#2
FACE PLATE INSIDE COVER (ASM.)
1
8
387772
FACE PLATE TENSION PILE
(2)
9
387775
FACE PLATE INSIDE COVER GUARD
(1)
10
387773
FACE PLATE INSIDE COVER PILE (RIGHT)
(1)
11
387774
FACE PLATE INSIDE COVER CAUTION SEAL
(1)
12
387843
LAMP CAUTION SEAL
(1)
13
387771
FEED BAR PILE
(1)
14
386080
HEIGHT ADJUSTING SPRING
1
15
387445
UNDER SIDE COVER (ASM.)
1
16
387444
UNDER SIDE COVER
(1)
17
387440
RUBBER WASHER
(4)
18
387446
UNDER SIDE COVER
(1)
19
386507
SCREW
(2)
20
283502
SCREW
1
21
283502
SCREW
5
22
387717
FACE PLATE (ASM.)
1
23
386528
SCREW
(1)
24
387716
FACE PLATE
(1)
25
387722
FACE PLATE COVER REINFORCING PLATE
(1)
26
386528
SCREW
(2)
27
387723
FACE PLATE COVER WINDOW
(1)
28
387721
HINGE FIXING PLATE (ASM.)
1
29
387752
NEEDLE THREAD END HOLDING SPRING
(1)
30
386528
SCREW
(1)
31
387718
FACE PLATE HINGE (ASM.)
(1)
32
387719
FACE PLATE COVER SPRING
(1)
33
283491
SCREW
(2)
34
283524
SCREW
(2)
35
387720
HINGE FIXING PLATE
(1)
36
387751
NEEDLE THREAD END HOLDING PLATE (ASM.)
(1)
37
387397
SCREW
(1)
38
387734
BASE TENSION COVER (ASM.)
1
39
387733
BASE TENSION COVER
(1)
40
387726
BASE TENSION COVER PILE
(1)
41
#3
BASE TENSION COVER PILE 2
(1)
42
387786
BOBBIN WINDER THREAD GUIDE (ASM.)
1
43
*
387787
BOBBIN WINDER THREAD GUIDE SPRING
(1)
44
*
283478
SCREW
(1)
45
*
387785
BOBBIN WINDER THREAD GUIDE
(1)
46
388011
BELT COVER (ASM.)
1
47
388010
BELT COVER
(1)
48
387871
CONTROLLER RECEPTACLE (ASM.)
(1)
49
283355
BAND
(1)
50
283522
SCREW
(1)
51
388014
CARD LID
(1)
52
386528
SCREW
(1)
53
283502
SCREW
2
54
387442
AUXILIARY BED (ASM.)
1
55
387441
AUXILIARY BED
(1)
56
387443
AUXILIARY BED COVER
(1)
57
386086
AUXILIARY BED SUPPORTING PLATE (ASM.)
(1)
58
283522
SCREW
(2)
59
388031
BUTTONHOLE FOOT (ASM.)
(1)
60
386015
INVISIBLE ZIPPER FOOT (ASM.)
(1)
61
388032
ZIPPER FOOT (ASM.)
(1)
62
388033
BLINDSTITCH PRESSER FOOT (ASM.)
(1)
63
388034
OVER CASTING FOOT (ASM.)
(1)
64
387336
EMBROIDERY PRESSER FOOT (ASM)
(1)
65
388041
DECORATIVE STITCH FOOT (ASM.)
(1)
66
283392
EYELET PUNCH
(1)
67
283394
SCREWDRIVER
(1)
68
385098
SEAM RIPPER
(1)
69
283401
RULER
(1)
70
283403
BRUSH
(1)
71
388039
THREADING GUIDE (ASM.)
(1)
72
388029
BOBBIN (ASM.)
(2)
73
385096
BOBBIN
(2)
74
387735
BASE TENSION SEAL
1
75
387439
UNDER SIDE COVER
1
76
386520
SCREW
2
77
283471
SCREW
1
78
386520
SCREW
1
79
283488
SCREW
1
80
386520
SCREW
2
81
386087
HEIGHT ADJUSTING SCREW
1
82
283470
SCREW
1
83
#4
BELT GUITE (UPPER)
1
84
#4
BELT GUITE (LOWER)
1
85
#4
SCREW
4
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
- 2 -
