REF
NO. NOTE PART NO. PART D E S C R I P T I O N Qty
1
387433
HANDLE (ASM.)
1
2
387432
HANDLE
(1)
3
387434
HANDLE FIXING PLATE
(1)
4
387419
WASHER
(2)
5
387435
HNADLE SHAFT
(2)
6
283460
E RING
(4)
7
283502
SCREW
3
8
387006
BAND
1
9
387825
REAR PANEL (ASM.)
1
10
387824
REAR PANEL
(1)
11
387337
THREAD HOLDING PLATE (ASM.)
(1)
12
*
387826
THREAD HOLDING PLATE COVER
(1)
13
*
387827
THREAD HOLDING PLATE COVER FIXING PLATE
(1)
14
*
387783
PIN
(2)
15
387838
THREAD HOLDING PLATE COVER MAGNET
(1)
16
387832
BOBBIN WINDER SHAFT COVER (ASM.)
(1)
17
387831
BOBBIN WINDER SHAFT COVER
(1)
18
387833
BOBBIN WINDER SHAFT COVER SPRING
(1)
19
283487
SCREW
(1)
20
387834
BOBBIN WINDER SHAFT COVER FIXING PLATE
(1)
21
387835
BOBBIN WINDER SHAFT COVER PIN
(1)
22
283522
SCREW
(1)
23
387828
THREAD STAND POST
(1)
24
387829
THREAD STAND POST SHAFT
(1)
25
283458
E RING
(1)
26
387830
FELT
(1)
27
387437
BOBBIN WINDER SEAT (UPPER)(ASM.)
(1)
28
387150
WASHER
(1)
29
283522
SCREW
(1)
30
387839
PANEL CAP
(1)
31
387338
TOP THREADING CUTTER
(1)
32
387836
STOPPING PLATE
(1)
33
283522
SCREW
(1)
34
387837
THREADING THREAD GUIDE
(1)
35
387150
WASHER
(1)
36
283472
SCREW
1
37
387142
SCREW
1
38
387154
SCREW
1
39
283502
SCREW
2
40
283500
SCREW
1
41
387693
BH SWITCH FIXING PLATE (TOTAL ASM.)
1
42
387692
BH SWITCH FIXING PLATE (PARTIAL ASM.)
(1)
43
283459
E RING
(1)
44
387691
BH SWITCH FIXING PLATE (ASM.)
(1)
45
387694
AUXILIARY ROLLER FLOAT PLATE
(1)
46
387696
PRESSER LIFT SWITCH WORKING PLATE (ASM.)
(1)
47
283459
E RING
(1)
48
283459
E RING
(1)
49
283528
WASHER
(1)
50
387700
BH CHANGE-OVER PLATE (ASM.)
(1)
51
387702
POTENTIOMETER ARM SETSCREW
(1)
52
283469
SCREW
(1)
53
387701
BH SWITCH (ASM.)
(1)
54
387703
POTENTIOMETER SPRING
(1)
55
387704
POTENTIOMETER (ASM.)
(1)
56
387744
PRESSER LIFT SWITCH (ASM.)
(1)
57
283485
SCREW
(1)
58
283217
LOCKNUT
(1)
59
283355
BAND
(1)
- 4 -
