REF
NO.
NOTE
PART NO.
PART D E S C R I P T I O N
Qty
1
387663
DELIVERY STM FIXING PLATE (ASM.)
1
2
387665
AUXILIARY ROLLER ARM (TOTAL ASM.)
1
3
387664
AUXILIARY ROLLER ARM (ASM.)
(1)
4
387666
AUXILIARY ROLLER FIXING PLATE (ASM.)
(1)
5
387671
ROLLER GEAR GUIDE A (ASM.)
(1)
6
*
387670
ROLLER GEAR GUIDE A
(1)
7
387673
ROLLER GEAR GUIDE A PILE
(1)
8
283459
E RING
(1)
9
387672
ROLLER GEAR GUIDE B
(1)
10
387667
DELIVERY ROLLER THREAD GUIDE
1
11
283460
E RING
1
12
387689
DELIVERY ROLLER THREAD GUIDE PILE
1
13
387668
AUXILIARY ROLLER ARM SPRING
1
14
387339
DELIVERY STM
1
15
283491
SCREW
2
16
387669
DELIVERY STM RELAY LEAD WIRE (ASM.)
1
17
#10
THREADING BODY
1
18
387675
THREADING BODY SPRING
1
19
283459
E RING
1
20
387676
THREADING BODY LINK (ASM.)
1
21
283459
E RING
1
22
387677
THREADING WORKING BODY
1
23
283459
E RING
1
24
387678
THREADING BODY INTERMEDIATE GEAR
1
25
387679
DELIVERY ROLLER SHAFT
1
26
387681
DELIVERY ROLLER
1
27
387682
DELIVERY ROLLER GEAR
1
28
283506
SCREW
1
29
387783
PIN
1
30
283459
E RING
1
31
387683
THREADING BODY DRIVE GEAR
1
32
387690
THREADING BODY DRIVE GEAR WASHER
2
33
283463
E RING
1
34
387684
DELIVERY DRIVE GEAR
1
35
387685
DELIVERY DRIVE GEAR SPRING
1
36
387680
DELIVERY ROLLER BEARING
2
37
387686
DELIVERY STM CHANGE-OVER PLATE
1
38
387687
HINGE SCREW
1
39
387688
SPRING
1
40
387728
BASE TENSION (ASM.)
1
41
*
387727
BASE TENSION
(1)
42
*
387730
BASE TENSION SPRING
(1)
43
*
387729
BASE TENSION DISK (ASM.)
(1)
44
*
387415
WASHER
(1)
45
*
283458
E RING
(2)
46
*
387731
BASE TENSION CLICK
(1)
47
*
283486
SCREW
(1)
48
283488
SCREW
1
49
387736
THREAD RELEASE CAM (ASM.)
1
50
283460
E RING
1
51
387749
THREAD RELEASE LINK (UPPER)
1
52
283459
E RING
1
53
387739
THREAD RELEASE PLATE (ASM.)
1
54
*
387738
THREAD RELEASE PLATE
(1)
55
*
387740
THREAD RELEASE ADJUST PLATE
(1)
56
*
385339
SCREW
(1)
57
*
387741
THREAD RELEASE CHANGE-OVER ADJUST PLATE
(1)
58
*
385339
SCREW
(1)
59
283460
E RING
1
60
387732
BASE TENSION FLOAT
1
61
283460
E RING
1
62
283502
SCREW
3
63
387006
BAND
1
64
283322
CORD HOLDER
1
65
283073
THREAD RELEASE CAM SPRING
1
66
387698
AUXILIARY ROLLER FLOAT LINK (ASM.)
1
67
*
387695
AUXILIARY ROLLER FLOAT ADJUST PLATE (ASM.)
(1)
68
*
387697
AUXILIARY ROLLER FLOAT LINK
(1)
69
*
283459
E RING
(1)
70
283488
SCREW
1
71
388119
THREAD GUIDE NO1.(TOTAL ASM)
1
72
#9
THREAD GUIDE NO. 1 (ASM.)
(1)
73
#9
NEEDLE THREAD DETECTION SHIELD PLATE
(1)
74
#9
NEEDLE THREAD DETECT CIRCUIT BOARD INSULATED SHEET
(1)
75
388001
SHILED PLATE SPRING
(1)
76
387415
WASHER
(1)
77
#9
NEEDLE THREAD DETECT CIRCUIT BOARD (ASM.)
(1)
78
387743
THREAD GUIDE NO. 1 COVER
(1)
79
283522
SCREW
(1)
80
387388
E RING
(1)
81
283491
SCREW
(1)
82
387006
BAND
(1)
83
#3
DELIVERY ROLLER THREAD GUIDE PILE A
2
84
283502
SCREW
1
85
283355
BAND
1
86
387151
WASHER
1
FOR THE PARTS TO WHICH "#" IS WRITTEN IN THE PART NO. COLUMN,
REFER TO THE LIST AT THE END OF PARTS LIST.
