Chapter 3
Installation and Setup
This section shows T8Pro installation in difference work mode, including use the helix antenna
and geodetic antenna.
3.1 Helix antenna
Below picture is about how T8Pro connect with Helix antenna. Then can conduct the position
collection work after fixed the helix antenna well. Suggest make the antenna head to sky.
3.2 Geodetic antenna
Below shows how T8Pro connect with the geodetic antenna. Use the provided cable make the
connections.
