13
F F
5. PROBLEMS AND SOLUTIONS
1. How far is the monitoring range?
In daylight the camera has a visual distance of 50 meters.
With infrared night vision the visual distance is about 15
meters.
2. The Smart Outdoor Camera gives the status “offline”
after connecting.
• Ensure the WiFi password for your home network is entered
correctly in the settings menu of the “Doby” application.
• Ensure your mobile device is connected to the same WiFi
network as your camera to make the initial connection.
3. The SD Card cannot be detected.
Please ensure the SD card is formatted as FAT32.
6. TECHNICAL SPECIFICATIONS
Lens: Wide-angle lens
Angle: Diag. 105°, horiz. 90°, vert. 60°
Video compression: H.264
Resolution: 1280 960 @15fps
Audio: Single microphone
WiFi Protocol Support: IEEE802.11 b/g/n (2.4GHz)
Encryption: WPA2 / WPA / WEP / OPEN
Network: Wi-Fi/Cable RJ45
Power: 12V/1A
Operating Conditions: Temperature -30~60°C,
Humidity <90%
Size: 67 105 145mm
