SINO PEVC2201E - Product Technical; Specifications

3
2. Product Technical
2.1. Specifications
Parameter Type
Description
PEVC2201E
PEVC2201U
Input
Power Supply
1P+N+PE
3P+N+PE
1P+N+PE
Rated voltage
230VAC±10%
400VAC±10%
220VAC±10%
Frequency
50/60Hz
Output
Number of output ports
1
Voltage
230VAC±10%
400VAC±10%
220VAC±10%
Rated Current
16A/32A
Power Rating
3.7kW/7.4kW
11kW/22kW
1.8kW/3.5kW/7kW
Safety
Electrical protection
Over/under voltage protection,Over current protection, Short
circuit protection, Over/Under temperature
protection,Lightning protection,ground protection
RCD
Type A + 6mA DC
Protection level
IP55
Impact protection
IK08
Certification
CE
Standards
IEC61851-1,IEC62196-1/2,SAE J1772-2017
Environmental
Operating temperature
–30℃~+50℃
Storage temperature
–40°C~+80°C
Altitude
≤2000m
Humidity
≤95%,non-condensing
Basic
parameters
Energy meter
Accuracy Class 1 energy meter
HMI
4.3 inch LCD
Plug cable length
5m
Communication
Bluetooth/WiFi/ Ethernet/ 4G LTE
Protocol
OCPP-1.6J
Connector type
Type 2
Type 1
Installation method
Wall-mount/column-mount
Shell color
Metallic grey
Shell material
(ABC+PC)-Blend
Start mode
Plug&play/RFID card/APP
