Installing Internal Antenna Cable

TaketheSMAConnector(A)andplugintoIOPanel(D).PuttheWasher(B)intothe
SMAConnector(A),thenputtheO‐ring(C)toSMAConnector(A)andtightenas
showninthepicture.



TaketheIpexConnector(A)andpressontheWi‐Fimodule/3G
module/GPSmodule
(GPS,onlysupportpassiveAntenna)
A
B
C
D
A
