SIP 01480 - Page 2

1
1
Saw blade
14 Suction socket
2 Riving knife 15
Machine feet
x 4
3 Work table 16
Rip fence guide profile with ruler
4 Rip fence 17 Rip fence bracket
5 Holder for suction hose 18 Handwheel saw blade tilting
6 Table extension 19
Hand wheel height adjustment saw blade
7 Suction hose 20
ON-OFF-switch
8 Saw blade guard 21
Locking handle saw blade tilting
9
Cross-cut fence
22
Connecting block work piece downholder
10 Stopper cross-cut fence 23
Cross-cut fence bracket
11
Sliding table
24
Work piece downholder
12
Sliding table base profile
25
Mitre fence
13 Guide profile without ruler
1.
Components 01480 SIP 10" Compact Cast Iron Table Saw
