> APPLIANCES PROVIDED WITH THER-
MAL VALVE (OPTIONAL)
This device enables the machine’s by-pass op-
eration through automatic water discharge
whenever it reaches a temperature of nearly
60°C and cooling working components.
•
WARNING:
appliances that are not provided with
this disposal must not operate for more than 2 minutes
with released gun. Recycled water raises its temperature
remarkably causing great damages to the pump.
>
DETERGENT SUCTION
(see g.
B)
NOZZLE
at low pressure
(see g.
E
)
The adjusting head allow you to select water jet at
low and high pressure. The pressure selection is car
-
ried out by rotating the adjusting head. To increase
the pressure, rotate the adjusting head clockwise,
to reduce the pressure rotate it anti-clockwise. The
detergent suction is automatic when the adjusting
head of the lance is rotate for low pressure operation
(anti-clockwise).
•
CAUTION: Make use only of liquid detergent, do not
absolutely use acid or too much alkaline products.
We suggest you to make use of our products, which
have been studied for the use with washer machines.
CARE AND MAINTENANCE
(vedi g.
L
)
IMPORTANT: Before doing any work
on the cleaner, discharge the pressure
and disconnect the electricity and water
supplies.
CHECKING THE PUMP OIL LEVEL
Check the oil level periodically. The oil must be
changed for the rst time after 50 working hours,
with subsequent changes every 500 hours. SAE
20/30 , 15W-40, 20W-40 (600 gr) oil is recommended
.
CHECKING THE WATER INTAKE FILTER
Inspect and clean the water intake lter on the inta
-
ke union periodically. This is important to prevent
fouling which may impair operation of the pump.
CHECKING THE SPRAY ROD NOZZLE
Replace the nozzle when the pressure drops
below the normal values.
DESCALING
The descaling procedure must be carried out periodically
with specic products. The interval depends on the hard
-
ness of the water. Pour one litre of product for every 15
litres of water into a drum containing at least 30 litres of
water. Disconnect the gun from the high pressure line and
place its free end in the drum, in order to form a closed cir
-
cuit, and draw the solution into the machine for at least 10
minutes. The delivery end of the line should discharge into
a canvas or mesh bag so that the scale removed is not re
-
turned to the circuit. Then restore the normal connection
and rinse with plenty of cold water. This operation should
be carried out by our after-sales service, since the descal
-
ing product may cause wear of components. Comply with
the regulations in force when disposing of the descaling
agent.
ELECTRIC DIAGRAM
See illustrations,
I
.
WATER DIAGRAM
See illustrations,
H
.
TROUBLESHOOTING
Before doing any work on the machine, disconnect
the electricity and water supplies and discharge the
pressure. Proceed systematically to identify Faults
following the chart below; if you are still unable to
eliminate the problem, call in the Authorized After-
Sales Service.
Fault
When switch “ON” the ma-
chine will not start work-
ing
Cause
• Plug not properly inserted in
socket.
• Electric socket is faulty.
• The main voltage is insucient.
• The pump is stuck.
• Gauge of extension lead not
sucient.
EN
12
