10
GETTING TO KNOW YOUR INVERTER GENERATOR
Ref. No. Description Ref. No. Description
1 Exhaust 10 Economy Control Switch
2 Choke 11 Recoil Starter
3 Fuel Cap 12 DC Socket
4 Primer Bowl 13 DC Circuit Breaker
5 Fuel Valve 14 AC Socket
6 Maintenance Panel A 15 Low Oil Indicator
7 Engine Switch 16 Pilot / Power Indicator
8 Earth / Ground Terminal 17 Overload Indicator
9 Maintenance Panel B
03953: Ti-2002
4
5
6
3
2 1
12 11 10
13
14
7 8
17 16 15
9
23
EXPLODED DRAWING
