SIP Medusa Ti-2002 User Manual

8
TECHNICAL SPECIFICATIONS
Name Medusa Ti-1002 Medusa Ti-2002
Part number 03951 03953
Engine type 4-stroke, single cylinder, air
cooled, OHV
4-stroke, single cylinder,
air cooled, OHV
Engine size 144 cc 152 cc
Fuel type Unleaded petrol Unleaded petrol
Rated output (peak) 1000 watts 2200 watts
Rated output (continuous) 900 watts 2000 watts
AC voltage 230v ~50hz 230v ~50hz
DC voltage 12v 12v
DC current (max.) 5 amp 8.3 amp
Fuel tank capacity 2.7 L 6.5 L
Sound power (LwA) 90 dB(A) 92 dB(A)
25
PARTS LIST….cont
54-13 Filter Tube PW01-00140 66-6 Fuel Pump Cover PW01-00146
54-14 Cross Head Screw M3x8 PW01-00140 66-7 Cross Head Screw M3x12 PW01-00146
54-15 Filter Case Connector PW01-00140 67 Clip 7mm PW01-00027
54-16 Filter Case PW01-00140 68 Vacuum Pump Outlet PW01-00147
54-17 Hex Nut M3 PW01-00140 69 Clip 8mm PW01-00022
54-18 Carburettor Gasket PW01-00140 70 Vacuum Pump PW01-00148
54-19 Choke Assembly PW01-00140 71 Clip 7mm PW01-00027
54-20 Block Spring PW01-00140 72 Vacuum Pump Inlet PW01-00149
54-21 Step Motor PW01-00140 73 Clip 8mm PW01-00022
54-22 Cross Head Screw M3x8 PW01-00140 74 Self Tapping Screw 4.8x16 PW01-00061
54-23 Choke Block PW01-00140 75 Fuel Valve PW01-00150
54-24 Cross Head Screw M4x12 PW01-00140 76 Plastic Case Left PW01-00151
54-25 Step Motor Support PW01-00140 77 Cross Head Screw M5x30 PW01-00152
54-26 Choke Lever Assembly PW01-00140 78 Maintenance Cover Left PW01-00153
54-27 Washer M3 PW01-00140 79 Bolt M6x16 PW01-00154
54-28 Cotter Pin PW01-00140 80 Cross Head Screw M4x25 PW01-00155
54-29 Choke Lever Spring PW01-00140 81 Bulb Ring Holder PW01-00156
54-30 Choke Lever PW01-00140 82 Self Tapping Screw 4.2x16 PW01-00157
55 Clip 8mm PW01-00022 83 Battery Access Cover PW01-00158
56 Carburettor Inlet PW01-00141 84 Cross Head Screw M4x16 PW01-00065
57 Clip 8mm PW01-00022 85 Washer M4 PW01-00064
58 Fuel Filter PW01-00142 86 Fuel Valve Knob PW01-00159
59 Clip 8mm PW01-00022 87 Square Clip Nut PW01-00060
60 Air Tube PW01-00143 88 Case Bracket PW01-00160
61 Clip 8mm PW01-00022 89 Cross Head Screw M5x8 PW01-00161
62 Self Tapping Screw 4.8x16 PW01-00061 90 Flange Bolt M5 PW01-00077
63 Clip 9mm PW01-00020 91 Recoil Cover Frame PW01-00162
64 Fuel Pump Tube PW01-00144 92 Control Panel Assembly PW01-00163
65 Hex Nut M4 PW01-00145 93 Self Tapping Screw 4.2x13 PW01-00093
66 Fuel Pump Assembly PW01-00146 94 Cross Head Screw M5x12 PW01-00018
66-1 Fuel Pump Base PW01-00146 95 Maintenance Cover Top PW01-00164
66-2 Fuel Pump Pad PW01-00146 96 Maintenance Cover Right PW01-00165
66-3 Fuel Pump Spring PW01-00146 97 Square Clip Nut PW01-00060
66-4 Spring Washer PW01-00146 98 Clip 10mm PW01-00048
66-5 Fuel Pump Rubber PW01-00146 99 Air Pipe PW01-00166
