ASSEMBLY INSTRUCTIONS
FITTING THE HANDLE TO THE FRAME
CONNECTING THE HOSE / PISTOL / LANCE
Slide the handle assembly over the main frame.
Ensure that the holes line up and secure in place with the bolt, washer and
hand wheel as shown.
Push the threaded section of the lance into the threaded section of the pistol
assembly (see below, left).
Turn the threaded section of the pistol to fully secure.
Fit one end of the high pressure hose to the fitting on the pistol assembly (see
below, right).
Turn the fitting on the hose clockwise to fully secure.
Note: Ensure that the square section of the bolt sits in the hole on the inside
of the frame; This will stop the bolt from spinning and make tightening
much easier.
Lance Pistol
Pistol
Hose
Handle
Main Frame
Now push the other end of the high pressure hose into the water outlet (see
page 10).
Turn the fitting on the hose clockwise to fully secure.
19
MAINTENANCE INSTRUCTIONS
Caution: Always turn off the pressure washer and allow to fully cool before
carrying out any maintenance procedures.
CHANGING THE OIL
Clean or Replace The Air Filter (every 50 hours of use)
1. Remove the air filter cover screws.
2. Remove the air filter cover.
3. Remove the air filter element.
4. If the air filter is damaged contact your local distributor to purchase a replace-
ment, If the filter is dirty wash the filter in a solution of warm water and mild deter-
gent and rinse thoroughly. Leave the filter to dry completely, once dried immerse
the filter in clean engine oil and squeeze the filter to remove excess oil - the filter
should only be damp with oil.
5. Put the filter back into its original position and refit the air filter cover etc.
Change The Engine Oil (every 50 hours of use).
1. Turn the oil filler cap counter clockwise and remove from the crankcase.
2. Loosen and remove the oil drain bung and allow the oil to drain into a suitable
container.
3. Refit and tighten the oil drain bung once all of the oil has drained.
4. Fill the crankcase to the max level with fresh oil (see page 11); we recommend
the use of SAE 10W30 oil.
5. Refit the oil filler cap.
CLEAN OR REPLACE THE AIR FILTER
CLEAN OR REPLACE THE SPARK PLUG
Clean or Replace The Spark Plug (every 50 hours of use).
1. Remove the spark plug cap from the spark plug.
2. Use the supplied spark plug spanner to remove the spark plug.
3. Check for discoloration and remove any carbon build up.
4. Check the spark plug gap, it should be between 0.6 and 0.7mm; Adjust if neces-
sary.
5. Check the overall condition of the plug and replace if damaged.
6. Reinstall the plug and refit the spark plug cap.
