OPERATING INSTRUCTIONS….cont
USING DETERGENT
Place the filter end of the detergent hose into the detergent container (not sup-
plied).
The detergent will flow through the hose/pistol/lance along with the water when
the trigger is pressed.
Detergent Hose
Detergent Inlet
Lance
Quick Coupler
Black Nozzle
To use the detergent function, the black low pressure nozzle has to be fitted.
Ensure that the detergent hose is fitted to the detergent inlet.
11
CONNECTING TO A WATER SUPPLY
FITTING THE DETERGENT HOSE
Simply push the detergent hose over the detergent inlet.
The pressure washer is supplied with an equivalent hozelock type adaptor.
The easiest way to connect to a water supply is to fit the equivalent female fitting to
the end of the supply hose.
Once connected, the water supply can be turned on.
ASSEMBLY INSTRUCTIONS….cont
Water Inlet
Detergent Hose
Detergent Inlet
Water Outlet
Hose
