16
Vehicle Installation
Step 2: Install the Dash or Vent Mount
Follow the instructions on the next several pages for the mounting method you
have selected.
NOTE! The PowerConnect Vehicle Dock included with Onyx is compatible with the
T-slot style Dash and Vent Mounts. If you have an existing Dash Mount or Vent
Mount in your vehicle, you can continue to use it with this dock, and skip this step.
Installing the Dash Mount:
CAUTION! The adhesive used on the Dash Mount may be difficult
to remove. Do not install this mount on leather surfaces (contact
your automobile dealership if you are unsure about your dash
surface), and make sure the air temperature is at least 60°F
(15°C) during installation. If it’s not at least 60°F, turn on the
heater in your vehicle to bring the temperature up to 60°F.
1. Locate a flat surface for the Dash Mount. Make sure there is ample
room for the PowerConnect Vehicle Dock and Onyx Radio when
installed.
2. Set the orientation of the Dash Mount before adhering it. Loosen the
knob and adjust the adhesive foot for the location you selected in “Step
1: Choose a Location for Your
Radio” on page 11.
•Option 1 & Option 3
should be oriented as I.
•Option 2 should be oriented
as II.
3. The dock mounting plate can
be tilted in different directions. Adjust as necessary for your particular
To Next Page
