4.Piace and tighten the
bearing@
and
pulley@
at its original position. Then,
assemble the belt with the right side pulley
@ , and then assemble on the left side
pulley®
. (Fig.20,21 ,22)
11!22/Fig.22
S.Tighten the upper cover(]), oil reservoir®,
oil
baffle®, motor
cover@,
and the belt
cover@
on the machine. (Fig. 20, 23)
