Siruba VC008A Parameter Manual

3
2. Installation and Adjustment:
(1). Motor installation:
M5 interlock mode motor installation:
1. Takes off the heat exhaust fan and pulley of sewing machine.
2. Puts coupling
○
A into shaft of sewing machine，heat exhaust fan closes to shaft.
3. Fix the set screw
○
B of coupling. Warning ：Clamp sets crew of coupling must fix in flat surface
of shaf
t or carve
○
C.
4. Fix the fan
cover
○
D of motor.
5. Fix M 5 motor on fan cover
○
E.Warning：There is against dull design for coupling of sewing and
motor, joint di
rection must pay more attention on it.
6. Fix fan cover of motor
○
F.
Adjust on needle position
1. First step: takes off the exhaust fan of motor.
2.
Turn the shaft gets the scale to stop at
highest
point (o
r the up position point in sewing machi
ne).
3.
Turn the encoder disc to screw (A) to
aim at the
wire outlet of motor
.
Remark：Above description is a standard of position
adjustment, if the position is not satisfy
pleases adjust till it match your
requirement.
○
F
○
E
○
B
○
C
○
A
There is against dull design for coupling of
sewing and motor, joint direction must pay
more attention on it.
Clamp sets crew of coupling
must fix in flat surface of shaf
t
or carve ○
C
.
○
D
Wire Outlet
Screw (A)
Screw (B)
Retlector Slice base
Exhaust fan
