SIRUI P-424FS - Retractable Legs; 360° Panning System

1/16 2/16
1. Parts Name 2. Retractable Legs
3. 360° Panning System
360° Panning
Section
The wrist strap can be easily taken off.
a.Unlock
b.Extend or retract
c.Lock
Twist the Upper Twist Collar to lock/unlock the
main tube section.
Clockwise Turn: Secure
Counter-clockwise Turn: Unlock
3/8" and 1/4" Mounting Screw
Mounting Platform
Top Quick Release Sleeve
Flip Locks
Upper Twist Collar
Wrist Strap
Bottom Quick Release Sleeve
Tripod Base
Release Button
Rubber
Foot
Ball Locking Knob
