2.
1.
5.
4.
6.
3.
9.
7.
11.
12.
13.
14.
10.
15.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
OVERVIEW
1
8.
Machine Head
Flip Cover
Touch Screen
Cutting Strip
Tool Holder
Holds cutting blade housing or
marker adapter
Feed Tray
Helps stabilize material
Adjustable Pinch Rollers
Feeds material in and out of the
cutter
Grit Marks
Power Button
Pinch Roller Levers
Adjusts the tension of the pinch
rollers
USB-A Port
Used for connecting flash drives
to cutter
USB-B Port
Used for connecting cutter to a
computer
DC Power Port
Roller Bar Lever
Locks down or releases material
under roller bar and allows pinch
rollers to be adjusted
Raised Feet
To Next Page
