Label Description
1 LAN Ports (1 – 4) Use an Ethernet cable to connect each port to a
computer on your Local Area Network (LAN).
2 Link Port Use an Ethernet cable to connect this port to your
WAN router/modem.
3 DC Connector Use the power cable and connect the adapter to the
power socket on the wall, and the DC inlet into the
DC connector.
4 WPS WPS (Wireless Push Button) is used for Wi-Fi
Protected Setup. By pressing this button, the
security settings of the device will automatically
synchronize with other wireless devices on your
network that support Wi-Fi Protected Setup.
