8
LED Definition
From left to right.
Port Description
LAN (Blue) Shows the cable is connected.
LAN (Blue) Shows the cable is connected.
LAN (Blue) Shows the cable is connected.
LAN (Blue) Shows the cable is connected.
WAN (Blue) Shows the cable is connected.
WiFi 5 GHz (White) Shows WiFi activity on the 5 GHz band.
WiFi 2.4 GHz (Blue) Shows WiFi activity on the 2.4 GHz band.
Power (Red) Shows the device is turned on.
WPS (Blue) Shows WPS activity after pushing WPS button.
Flashing = In progress
Solid = success
