LED Definition
As shown from the top to the bottom.
LED
Description
Power
Shows the device is turned on.
Internet
Shows the device is connected to the internet.
LAN
Shows the cable is connected.
LAN
Shows the cable is connected.
LAN
Shows the cable is connected.
LAN
Shows the cable is connected.
USB1
Shows a device is connected to the USB port.
USB2
Shows a device is connected to the USB port.
2.4GHz WiFi
Shows 2.4GHz WiFi activity.
5GHz WiFi
Shows 5GHz WiFi activity.
