SiT6731EB Evaluation Board User Manual
Table A1. Bill of Materials (BOM)
#
Reference
Designators
Description
Qty
SMD component size
Value
1
C1, C10
Capacitor
2
0603
10uF
2
C2, C5, C6
Capacitor
3
0402
0.1uF
3
C3, C4, C8, C9
Capacitors
4
0402
DNP
4
C7
Capacitors
1
0402
1uF
5
D1
LED
1
0603
Green
6
J1
SMA connector
1
-
-
7
FB1
Ferrite Bead
1
0805
600 Ω @ 100 MHz
8
P1
4-pin header
1
-
-
9
P2, P4
2-pin header
2
-
-
10
P3, P5
3-pin connector
2
-
-
11
R1
Resistors
1
0603
800 Ω
12
R2, R3, R5, R6, R8,
R9
Resistors
6
0603
DNP
13
R4, R10
Resistors
2
0603
0 Ω
14
R12
Resistor
1
0402
49.9 Ω
15
R13, R14
Resistor
2
0402
8.2 kΩ
16
R11, R16, R17, R18,
R19, R20
Resistor
6
0402
DNP
17
U2
Buffer
1
TSSOP8-TI
LMK1C1104
Table A2. Connectors Digi-Key Part Number
Connectors
Digi-Key
part number
Digi-Key
part number for
mating connector
Digi-Key
part number for
associated products
Power/ Power adjust
WM10159-ND
WM2002-ND
WM1114TR-ND
Pin 1 access
732-5335-ND
-
-
Pin 2 access
732-5335-ND
-
-
Frequency control via I
2
C
732-5336-ND
-
-
OUT
WM5534-ND
-
-
