6) MAINTENANCE POINTS
ITEM Q.ty DESCRIPTION OPERATION EVERY
HOURS
NOTES
1 1 GEARBOX LUBRICATE 100 SEE NOTE A
2 2 CENTRAL ROTORS LUBRICATE 50 *
3 2 LATERAL ROTORS LUBRICATE 50 *
4 4 SWIVEL HINGE PINS LUBRICATE 50 *
5 4 UNIVERSAL JOINTS LUBRICATE 8 *
6 2 KEYED COUPLING
FORK
LUBRICATE 8 *
7 1 3
rd
POINT HITCH LUBRICATE 8 *
8 4 WHEEL SUPPORTS LUBRICATE 8 *
9 2 ARM LINKAGE PINS CLEAN SEE
NOTE C
WITH
BRUSHES, etc
10 1 PTO CLEAN/
LUBRICATE
SEE
NOTE B
WITH
BRUSHES, etc
11 4 WHEELS CHECK
PRESSURE
SEE
NOTE C
INFLATE TO
35 PSI
12 1 CARDAN SHAFT SEE CARDAN SHAFT MAINTENANCE
13 * General checking of bolts, security pins and split pins to be carried out
initially after the first 8 hours of use. Subsequently every 50 hours and
whenever the machine is laid up for extended periods.
GREASE TYPE : NGLI 2 EP
NOTE A:
COMPLETE LUBRICATION OF THE CENTRAL GEARBOX 1:
The complete lubrication of gearbox 1 is done the first time at the manufacturer’s
plant, after which it must be topped up periodically, as according to the lubrication
points table. A complete change or fill is necessary only for the replacement and /or
repairing of the entire gearbox or internal parts. In this case, it is necessary to: remove
caps H-K and inject the grease, using grease pump W, into hole T until the grease
comes out of hole K. Then screw caps H-K back into place on central gearbox 1.
Periodic checking and topping up of central gearbox 1:
Every 100 hours of working time, check and top up central gearbox 1. It is a good
practice, however, to check the condition and quantity of grease after all long periods
of inactivity, especially when starting to work again after the winter break. To top up
the grease in central gearbox 1 it is necessary to: remove caps H-K and inject the
proper amount grease into hole J, using grease pump W. Then screw caps H back into
place on housing 1.
B = Each time the Cardan shaft is disconnected and Whenever the machine is
stopped, we recommended that you clean the power takeoff shaft and replace the
protective cover (use additives of a type permitted by anti-pollution regulations).
C = Each time the machine is connected to the tractor.
