sitrex RT/5200 - PRODUCT IDENTIFICATION; Main Parts Identification; Technical Data

8
3) PRODUCT IDENTIFICATION
MAIN PARTS
1) 3
RD
POINT HITCH, DRAWBAR AND
PARKING STAND
2) MACHINE BODY
3) RH AND LH LATERAL ROTORS
4) RH, CENTER AND LH GUARD
5) RH AND LH TINE ARM
6) WHEEL ASSEMBLY
7) CARDAN SHAFT
8) HYDRAULIC KIT (only for RT/5200-H)
9) SHOCK ABSORBER
10) IDENTIFICATION PLATE
TECHNICAL DATA
All data are indicative. Sitrex reserves the right to change them without advance notice.
SPECIFICATIONS RT/5200
Manual fold
RT/5200-H
Hydraulic fold
Number of rotors 4 4
Tine arms per rotor 6 6
Working width 17' ( 5,20 m) 17' ( 5,20 m)
Transport width 10' 3'' (3,15 m) 10' 3'' (3,15 m)
Weight 1075 lbs (490 kg) 1090 lbs (495 kg)
Tire 16x6.50-8 16x6.50-8
PTO Tractor requirement 25 hp (18 kw) 25 hp (18 kw)
PTO slip clutch Standard Standard
Operating speed 10 mph (16 Km/h) 10 mph (16 Km/h)
