SK magic BID-S24D - Technical Specifications

28
English
The energy cost specified on the energy consumption efficiency label and the actual energy cost
may vary depending on actual user energy consumption, when the energy is used, or changes in
electricity bill prices.
148 mm
469 mm
537 mm
Product Name
BID-S24D
Rated Power Supply
120V~, 60Hz
Rated Power Consumption
955W
Power Cord Length
About 1.2m
Min-Max Operating Water Pressure
0.098MPa to 0.735MPa
Working Ambient Temperature
32 ~ 104˚F (0 ~ 40˚C)
Water Supply Method
Hydraulic
Supply Water Temperature
41 ~ 95˚F (5 ~ 35˚C)
Water Supply Control
Solenoid Valve
Dimensions (mm)
469 (W) X 537 (D) X 148 (H)
Weight
About 5.3kg
Technical Specifications
Product
Function
BID- S24D
Water temp.
Rear cleansing
Front cleansing
Move
Dry
Soft opening and closing
Massage
Child
Seat sensor
UV Nozzle Sterilization
Toilet bowl sterilization
