GENERAL DECK LAYOUT
General Deck Layout
Figure 4-2
9334-034
BOW LIGHT
RECEPTACLE
ANCHOR
STORAGE
TROLLING MOTOR
POWER SOURCE
BOW SEAT
MOUNT
(SEATS OPTIONAL)
BATTERY
MOUNTING/
OIL TANK
STERN
SEAT
MOUNT
FISH BOX
GENERAL
STORAGE
BAITWELL
ANCHOR LIGHT
RECEPTACLE
WASH-DOWN
OUTLET (OPTIONAL)
FIRE EXTINGUISHER
STORAGE
REMOVABLE
COOLER
ICE CHEST ZX 2400
FUEL
INLET
