SKF 226400
1. Description
The 226400 has a maximum pressure of 300 MPa (43 500 psi) and
delivers a volume per stroke of 0,23 cm
3
(0.014 in
3
). The oil injector
has a most varied usage when applying the SKF oil injection method.
Mounting and dismounting bearings, couplings and gearwheels are only
a few examples. The injector is supplied complete with repair kit 728383.
Everything is packed in a sturdy case.
2. Technical data
Maximum pressure 300 MPa (43 500 psi)
Volume per stroke 0,23 cm
3
(0.014 in
3
)
Oil container capacity 200 cm
3
(12.2 in
3
)
Oil outlet G
3
/4, external thread
Min. oil viscosity 300 mm
2
/s at operating temperature
Weight 2,2 kg (4.8 lb)
Designation 226400
Note: For applications where 400 MPa (58 000 psi) is required a special
model designation 226400/400 MPa is available.
