9SKF TIH 220m
English
TIH 220m/MV, TIH 220m/LV with 200V-3 phases, and all other three phases
supply execution
Colour of TIH 220m/xx wire Mains supply terminal
yellow / green ground
blue phase 1
brown phase 2
Connect the TIH 220m to only two of the three phases.
TIH 220m/LV with single phase supply
Colour of TIH 220m/LV wire Mains supply terminal
yellow / green ground
blue neutral
brown phase 1
4. Preparation for use
• Place the TIH 220m in the horizontal position on a stable surface.
• Connect the mains plug to a suitable mains supply.
• Plug the remote control into the connector on the carrying handle side of the heater.
• Slide the sliding yoke in open position. See the illustrations at the beginning of
this manual.
• For workpieces with an internal diameter large enough to fit over the induction coil,
follow these steps:
- Open the foldable bearing support and position them as shown on the
illustrations at the beginning of this manual.
- Place the workpiece over the induction coil using appropriate lifting equipment.
- For best performance, adjust the position of the workpiece so that the induction
coil is in the centre.
- Close the sliding yoke so that it completely covers the top of both
vertical supports.
• For workpieces that do not fit over the induction coil, follow these steps:
- Choose the largest of the two yokes that fit through the internal diameter
of the workpiece.
- Slide the workpiece onto the yoke that you have selected.
- Position the yoke on the TIH 220m with the bright underside resting evenly on
the two vertical supports.
• If you will use TEMP MODE, plug the temperature probe into the connector on the
carrying handle side of the heater. Place the magnetic end of the probe on the inner
ring of the bearing or on the innermost surface of the workpiece.
• Switch on the TIH 220m.
• Observe the self-test of the remote control display and signal tone.
