SKG 4098 - Technical parameters; TROUBLESHOOTING

20
8.2 Technical parameters
Rated load resistance: 500 Ω
Mode
Rated pulse
duration (µs)
Rated pulse repetition
frequencies (Hz)
Maximum amplitude
of output voltage (V)
1
40 ‒ 130
12 ‒ 67
62
2
74 ‒ 120
10
62
3
70 ‒ 138
33
62
 Output Waveform: see table above
 DC component: none
 Single pulses energy: <10 mJ (@ 1000 Ω)
 Output r.m.s: <10 mA or 10 mV (@ 500 Ω)
 No-load output: <500 V peak
 Adjustment of output amplitude: continuous uniformity, minimum output is not
more than 2% of maximum output.
 Surface magnetic field strength: ≥ 0.01T
 Heart therapy temperature: 37
o
C ~ 43
o
C
 Manufacturer will provide circuit diagrams, component part lists, descriptions,
calibration instructions to assist to service personnel in parts repair.
9. TROUBLESHOOTING
