1.Before installing the juice cup assembly, please ensure that the sealing ring of
the pulp outlet has been installed correctly on the base of bowl.
① Please insert the sealing ring of the pulp outlet into the rectangular narrow hole.
② Make sure the sealing ring plugs up the hole tightly.
05
06
Squeezing
rubber pad
① ②
2.Install the bowl on the main body.
Please insert it into the fixed point of
the main body.
When installing the bowl downwards,
the sign “▼”on it and “▲”on the main
body should be kept in line.
4.Connect the auger to the fine strainer.
With the small head of fine strainer
upwards, insert the auger and turn
clockwise until you hear sound of
“click”.
Assembling Method
5.Then insert the bottom of the
assembled auger into the hole of the
bowl.
6.Install the plate hopper.
When installing the plate hopper, the
unlocking label and “▲”on it should be
kept in line.
Then rotate it to make sure that the
locking pattern keeps in alignment with
the “▲”.
7.Place two cups. One is used to
contain juice and the other is used to
contain pulp. And put a filter into the
juice cup to separate the foam and pulp.
3.Assembling method of the juice cap
The juice cap is packaged separately.
Before use, align the bayonet of the
juice cap with the fixed columns on
the juice outlet and gently snap in.
