skike v07 Plus
Version 1.4.0711.1936 3
positioned as close as possible to the rear wheel. It is important to
ensure that the point from which affects the brake, will be modified.
The farther forward you are standing in skike, the later are the brakes.
The further back, the sooner.
The skike has a wing nut on one side (c). By loosening the wing nut and
●
move the heel strap (6), the position of the foot is also changed. The
coarse adjustment of the heel strap can be made in each case on the
opposite heel lift fixture means of attachment to differently positioned
holes.
Note: The distance between the heel (shoe) and rear wheel ,
however, should never be less than 10mm
D.3 Buckling and unbuckling
D.3.1 Buckling
Regard left and right!
●
The new foot belts with fixation can be easily opened and reared until
●
they stop.
First, slide the foot below the two foot straps when the shoe is on the
●
skike ground, slide the foot backwards into the heel strap (6).
Buckle up and start with the calf shell (5) , especially if there is no seat
●
available, a firmly stand is already provided after tightening of the calf
strap (5)
Just now tighten the Middle Belt (b), pressing on the lying down holding
●
strap on the shoe. Avoid shoe-knot or similar below the belt.
