INTRODUCTION
● This tool is intended for drilling in wood, metal, ceramic
and plastic; tools with electronic speed control and
left/right rotation are also suitable for screwing and
thread cutting
TECHNICAL SPECIFICATIONS 1
SAFETY
● Read and save this instruction manual (pay special
attention to the safety instructions at the back) 3
● Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working
● Check voltage indicated on nameplate of tool/charger/
battery
● In case of electrical or mechanical malfunction,
immediately switch off the tool or unplug charger from
power source
● SKIL can assure flawless functioning of the tool only
when original accessories are used
● Before using accessories always compare the maximum
allowed r.p.m. of that specific accessory with the r.p.m.
of the tool
● This tool should not be used by people under the age of
16 years
● Be careful not to drill or drive into areas where electrical
wires may be contacted
● Do not activate switch when changing accessories or
carrying the tool
CHARGING/BATTERIES
● Charge battery only with the charger that is supplied
with the tool
● Do not touch the contacts in the charger
● Do not expose tool/charger/battery to rain
● Never charge battery outdoors 4
● Store tool/charger/battery in locations where
temperature will not exceed 40° C or drop below 0° C
● Batteries will explode in fire, so do not burn battery for
any reason
● When damaged, and under extreme usage and
temperature conditions, batteries may start to leak
- if liquid comes into contact with the skin, wash quickly
with soap and water, then with lemon juice or vinegar
- if liquid gets into the eyes, flush eyes with clean water
for a minimum of 10 minutes and seek immediately
medical attention
● When battery is not in tool or charger, it should be kept
away from metal objects such as nails, screws, keys etc.
to prevent short-circuit
● Do not use charger when damaged; take it to one of the
officially registered SKIL Service Stations for a safety
check
● Do not use charger when cord or plug is damaged; cord
or plug should be replaced immediately at one of the
officially registered SKIL Service Stations
● Do not use battery when damaged; it should be replaced
immediately
● Do not disassemble charger or battery
● Do not attempt to recharge non-rechargeable batteries
with the charger
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
● Do not connect the blue (= neutral) or brown (= live) wire
in the cord of the charger to the earth terminal of the
plug
● If for any reason the old plug is cut off the cord of the
charger, it must be disposed of safely and not left
unattended
USE
● Charging battery 2
- battery of new tools is not fully charged
- insert battery into charger
- plug charger into power source
- after approximately 3-5 hours the battery is fully
charged
! remove battery from charger after charging period
has ended thereby lengthening the service life of
the battery
IMPORTANT:
- ensure that the outside surface of the battery is clean
and dry before inserting into charger
- do not charge at temperatures below 0° C and over
40° C; this will seriously damage the battery as well
as the charger
- do not remove battery from tool while it is running
- when you charge the battery for the first time, it only
accepts 80% of its maximum capacity; after several
charges and discharges, however, the batteries
should be at full capacity and deliver maximum
performance
- do not repeatedly recharge the battery after only a
few minutes of operation; this may result in a
reduction of operating time and battery efficiency
- the nickel-cadmium battery must be kept separate from
the natural environment and should not be disposed of
as normal domestic waste (symbol 5 will remind you
of this when the need for disposing occurs)
! prior to disposal protect battery terminals with
heavy tape to prevent short-circuit
- if you anticipate long periods of non-use for the tool,
it is best to unplug the charger from its power source
● Combined switch A 2 for on/off and speed control
Control the speed stepless from zero to maximum by
putting less or more pressure on the trigger
● Reversing switch B 26
For changing direction of rotation
● Mounting of accessories in chuck 7
Hold locking ring C in one hand while you with other
hand
- open the chuck by turning sleeve D counter-clockwise
- insert accessory
- close the chuck by turning sleeve D clock-wise
- firmly tighten sleeve D to ensure accessory is firmly in
place
! insert the accessory as deep as possible in the
chuck
! do not use accessories with a damaged shank
5
