SKIPIO SUF9-1 - SHR18-3;SSR18-3 Explode View

17
30229M0405
BOTTOM HINGE（R）GLASS
COMP NEK2150GK FRE
8
KR8AF00302
DOOR_1800（M）
24
BR84100100
DRYER
JG8AF00205
ASS'Y GLASS DOOR R
25
M729300102
DRAIN PAN
9
M722900106
DOOR_1800（R）
26
G8F5000200
CONDENSER FAN MOTOR
JG8AF00205
ASS'Y GLASS DOOR R
27
KF82100208
UNIT BRACKET(A)
10
KR89910402
TOP HINGE（R）
28
K3F3200901
LEVEL FOOT&CASTER
M722900108
TOP HINGE（R）GLASS
29
KG81200100
SMPS
11
KR91800201
EVAP DRAIN GUIDE
30
KG89600102
LED LAMP
12
KR91800102
AIR GUIDE(L/R)
13
KF81700100
EVA DUCT
14
G8F5000100
EVA FAN MOTOR
15
DK8A100104
EVAP ASSY REF
3-1-10. SHR18-3/SSR18-3Explode View
SHR18-3
