Dimensions
Fig. 171 Principle sketch: Vehicle dimensions
Vehicle dimensions for operating weight without driver (in mm)
» Fig. 171 Specification Value
A
Height
Basic dimension 1459/1471
a)
Vehicles with an off-road package. 1472/1484
a)
B
Front track
Basic dimension 1457
For vehicles fitted with the 1.2 l/55 kW MPI and 1.2 l/63 kW TSI engines and 14"
wheel rims.
1463
C
Width 1706
D
Rear track
Basic dimension 1494
For vehicles fitted with the 1.2 l/55 kW MPI and 1.2 l/63 kW TSI engines and 14"
wheel rims.
1500
E
Width including exterior mirror 1940
F
Clearance
Basic dimension 134
Vehicles with an off-road package. 141
G
Wheel base 2602
H
Length 4304
a)
Valid for vehicles with the Amundsen+ navigation system.
183
Technical data
