Angle
Fig. 172
Principle sketch: Departure an-
gle
Angle » Fig. 172
Overhang angle, front
Overhang angle, rear
Departure angle
The values shown indicate the maximum incline of an embankment, up which
the vehicle can drive at a slow speed without collision of the bumper or under-
body.
The values listed correspond to the maximum axle load, front or back.
Overhang angle (°)
Overhang angle, front Overhang angle, rear
13.8 16.5
A
B
184
Technical data
