SKY-WATCHER Star Adventurer 2i User Manual

6
The Optional Accessories:
(The default included accessories may vary. Please
refer to local dealers for details).
Fine-Tuning Mounting Assembly - To mount a telescope with
¼” thread screw on the Star Adventurer 2i. Allows pointing and
ne-tuning pointing in two directions.
3/8” Ball Head Adapter - To mount a standard camera ball-head
with 3/8” thread screw on the Star Adventurer 2i.
Equatorial Wedge - To adjust the latitude of the Star Adventurer
2i for polar alignment. O󰀨ers higher accuracy and stability than a
standard photo tripod head.
Counterweight - To balance the telescope or camera loading
with 1kg counterweight.
1/4" to 3/8" Convert Screw Adapter - To convert the default
socket for 3/8" thread screw to the socket for 1/4" thread screw
in order to mount the Star Adventurer 2i to a standard quick
release plate of the tripod with 1/4" thread screw.
Polar Scope Illuminator - To provide lighting source for Polar
Scope. Also compatible with Sky-Watcher EQ3, EQ5 and EQ8.

SKY-WATCHER Star Adventurer 2i Specifications

General

Payload Capacity	5 kg
Tracking Modes	Sidereal, Solar, Lunar
Wi-Fi	Yes
Mount Type	Equatorial
Latitude Adjustment	0° to 70°
Weight	1.2 kg
Smartphone Control	Yes
Tracking Rates	Sidereal, Solar, Lunar
Power Source	4 x AA batteries or external 5V USB
Connectivity	USB
Battery Life	Up to 72 hours
Compatibility	Compatible with most DSLR cameras
App Compatibility	iOS and Android
