SECTION 6, Page 11SJIII Series - The Conventionals 129919
Figure 6.1-4. Platform AC Outlet
Index
No.
Skyjack
Part No.
DescriptionQty.
A (Ref.) - AC OUTLET 110 Volt on PLATFORM (Models 3220/4620)
B (Ref.) - AC OUTLET 110 Volt on PLATFORM (Models 3226/4626)
C (Ref.) - AC OUTLET 110 Volt on PLATFORM (Model 4632)
D (Ref.) - AC OUTLET 220 Volt on PLATFORM (Model 3220/4620)
E (Ref.) - AC OUTLET 220 Volt on PLATFORM (Models 3226/4626)
F (Ref.) - AC OUTLET 220 Volt on PLATFORM (Models 4632)
1 130232 1 ELBOW, 90° Strain relief connector, A, B, C
2 131999 1 BOX, GFI Receptacle, A, B, C
132042 2 • RIVET, Pop 1/4” dia.
3 132007 1 PLATE, Outlet Box Support, A, B, C
4 109698 1 RECEPTACLE, 125V GFI, A, B, C
112327 4 • BOLT, Self-tapping #8-18 x 1/2”
5 109699 1 PLATE, Weatherproof cover, A, B, C
114678 2 • SCREW, Machine #6-32 x 1/2”
6 105269 1 CORD, 14/3 x 342" lg., A
1 CORD, 14/3 x 420" lg., B
1 CORD, 14/3 x 516" lg., C
117542 1 CORD, 14/3 x 408" lg., D
1 CORD, 14/3 x 492" lg., E
1 CORD, 14/3 x 588" lg., F
7 105271 1 PLUG, 3-Prong recessed, A, B, C
119913 2 • RIVET, Pop 5/32”
8 113227 1 SEAL, 110V Seal tite cover, A, B, C
9 136328 1 BOX, Outlet with fitting, A, B, C
134140 2 • RIVET, Open end dome 1/4” dia.
10 139641 2 • RIVET, Pop 1/4” dia.x 0.615”
11 134140 2 • RIVET, Pop 1/4” dia.x 0.740”
L (Ref.) 2 LABEL, AC Connection here
- (Refer to Figure 6.8-3)
NOTE: Compare the diagrams on the previous page with the AC
outlet on the machine to order the right parts.
