SECTION 6, Page 17SJIII Series - The Conventionals 129919
Figure 6.1-8. Main Platforms Assemblies
Index
No.
Skyjack
Part No.
DescriptionQty.
1 (Ref.) AR ASSEMBLY, Powered Extension Hydraulic Cylinder
(For components, refer to Figure 6.1-11)
2 125495 1 COVER, Cable guard LH
3 132042 4 RIVET, Pop 1/4” dia. x 5/8”
4 125494 1 COVER, Cable guard RH
5 125358 1 WELDMENT, Main platform - Model 3220 (Machines w/ manual extension deck)
125704 1 WELDMENT, Main platform - Model 3220 (Machines w/ power extension deck)
125361 1 WELDMENT, Main platform - Model 3226
6 125433 4 BUSHING, Slider
7 600738 2 PIN, Cotter (6.3mm x 40mm DIN 94)
8 125422 2 PIN, Rollout roller (@ platform)
9 125455 2 ROLLER, Extension platform wide
10 108773 1 ANGLE, Extension slider 1-1/8” x 1-3/8” x 1/8” x 22” (Model 32XX only)
11 600531 4 BOLT, Self tapping (3.5mm x 13mm DIN 7504)
12 600727 2 BOLT, Self tapping (6.3mm x 25mm DIN 7504)
13 125466 2 BUMPER, Platform
14 134559 2 ANGLE, Extension Slider (Model 46XX)
103632 4 SCREW, Hex Hd Self-tapping 1/4”-14 x 3/4”
15 104606 2 NUT, Hex Nylon Lock 3/8”-16 Gr. 5
16 130689 2 BUMPER, Platform Deck (Model 4620/4632 only)
17 133977 1 WELDMENT, Main platform - Model 46xx (Machines w/ power extesion deck)
(For Models 4620, order P/N 132503 for Machines with Serial No. 712974 & Below )
(For Models 4626, order P/N 132507 for Machines with Serial No. 713411 & Below )
133954 1 WELDMENT, Main Platform- Model 46xx (Machines w/ manual extension deck)
(For Models 4620, order P/N 132493 for Machines with Serial No. 712295 & Below )
(For Models 4626, order P/N 132485 for Machines with Serial No. 711863 & Below )
(For Models 4632, order P/N 132493 for Machines with Serial No. 711873 & Below )
