SECTION 6, Page 19SJIII Series - The Conventionals 129919
Figure 6.1-9. Extension Platform Assemblies
Index
No.
Skyjack
Part No.
DescriptionQty.
A 125583 1 EXTENSION DECK ASSEMBLY, Model 32XX 3’ Manual Extension
B 125457 1 EXTENSION DECK ASSEMBLY, Model 3220 6' Powered Extension Deck
C 133981 1 EXTENSION DECK ASSEMBLY, Model 46XX 4’ Manual Extension
(For Models 4620, order P/N 130221 for Machines with Serial No. 712295 & Below )
(For Models 4626, order P/N 130221 for Machines with Serial No. 711863 & Below )
(For Models 4632, order P/N 130221 for Machines with Serial No. 711873 & Below )
D 134018 1 EXTENSION DECK ASSEMBLY, Model 46xx 6’ Powered Extension Deck
(For Models 4620, order P/N 130380 for Machines with Serial No. 712974 & Below )
(For Models 4626, order P/N 132506 for Machines with Serial No. 713411 & Below )
1 125433 6 • BUSHING, Slider
2 125431 2 • ROLLER, Extension deck narrow
3 125424 2 • PIN, Extension deck roller (@ rollout arm end)
4 125356 1 • WELDMENT, Manual extension deck, A
133982 1 • WELDMENT, Manual extension deck, C
(For Models 4620, order P/N 130220 for Machines with Serial No. 712295 & Below )
(For Models 4626, order P/N 130220 for Machines with Serial No. 711863 & Below )
(For Models 4632, order P/N 130220 for Machines with Serial No. 711873 & Below )
5 107038 2 • BOLT, Button head 5/16”-18 x 7/8”, A
300064 2 • BOLT, Button head 5/16”-18 x 3/4”, C
6 103984 2 • NUT, Lock (hex) 5/16”-18 Gr. B, A, C
7 121042 1 • STOP, Extension deck, A
133037 1 • STOP, Extension deck, C
(For Models 4620, order P/N 121042 for Machines with Serial No. 712295 & Below )
(For Models 4626, order P/N 121042 for Machines with Serial No. 711863 & Below )
(For Models 4632, order P/N 121042 for Machines with Serial No. 711873 & Below )
8 125557 1 • WELDMENT, Power extension deck, B
133983 1 • WELDMENT, Power extension deck D
(For Models 4620, order P/N 132504 for Machines with Serial No. 712974 & Below)
(For Models 4626, order P/N 132505 for Machines with Serial No. 713411 & Below )
AH
