SECTION 6, Page 39SJIII Series - The Conventionals 129919
Figure 6.1-20. Scissor Arm Control Cable Assemblies
Index
No.
Skyjack
Part No.
DescriptionQty.
A 119643 1 CABLE ASSEMBLY, 10 Pin - Model 3220 & Model 4620 (ANSI/CSA No Option)
119644 1 CABLE ASSEMBLY, 10 Pin - Model 3226 & Model 4626 (ANSI/CSA No Option)
119646 1 CABLE ASSEMBLY, 10 Pin - Model 4632 (ANSI/CSA No Option)
119457 2 • CONNECTOR, Plug
1 102888 AR • CABLE, 16/10 (Refer to chart below for lengths)
2 102518 1 • SOCKET, 10 Pole, female
119456 2 • COVER, Connector
3 102766 1 • PLUG, 10 Pin, male
119949 4 • BOLT, Self thread #6-32
118711 4 • LABEL, Hydraulic proportional
B 119732 1 CABLE ASSEMBLY, 16 Pin - Model 3220 & 4620 (ANSI/CSA All Option & CE)
119733 1 CABLE ASSEMBLY, 16 Pin - Model 3226 & 4626 (ANSI/CSA All Option & CE)
119735 1 CABLE ASSEMBLY, 16 Pin - Model 4632 (ANSI/CSA All Option & CE)
4 102887 AR • CABLE, 16/15 (Refer to chart below for lengths)
5 107821 1 • CONNECTOR, Female 16 pin
103565 1 • • HOUSING, Top
103573 1 • • INSERT, Female
119727 4 • CODE PIN
6 107820 1 • CONNECTOR, 16 Pin male
103564 1 • • HOUSING, Top
103574 1 • • INSERT, Male
118711 4 • LABEL, Hydraulic proportional
C 119738 1 CABLE ASSEMBLY, 10 Pin - Model 4620 (EE Rated)
119739 1 CABLE ASSEMBLY, 10 Pin - Model 4626 (EE Rated)
119740 1 CABLE ASSEMBLY, 10 Pin - Model 4632 (EE Rated)
7 102888 AR • CABLE, 16/10 (Refer to chart below for lengths)
8 107777 1 • CONNECTOR, 10 Pin female
103566 1 • • HOUSING, Top
103571 1 • • INSERT, Female
119727 4 • CODE PIN
9 107778 1 • CONNECTOR, 10 Pin male
103563 1 • • HOUSING, Top
103572 1 • • INSERT, Male
118711 4 • LABEL, Hydraulic proportional
Models 3220/4620 3226/4626 4632
Cable Lengths 384” 468” 564”
