SECTION 6, Page 41SJIII Series - The Conventionals 129919
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.2-1. Scissor Arm Assembly - Model 3220 & 4620
A 125997 - Entire Scissor Assembly Model 3220 - Without Powered Extension (ANSI/CSA)
132580 - Entire Scissor Assembly Model 3220 - With Powered Extension (ANSI/CSA)
130581 - Entire Scissor Assembly Model 3220 - Without Powered Extension (CE)
132584 - Entire Scissor Assembly Model 3220 - With Powered Extension (CE)
B 134764 - Entire Scissor Assembly Model 4620 - Without Powered Extension (ANSI/CSA)
(Order P/N 132058 for machines with Serial No. 714053 & Below - Model 4620)
134765 - Entire Scissor Assembly Model 4620 - With Powered Extension (ANSI/CSA)
(Order P/N 132573 for machines with Serial No. 714053 & Below - Model 4620)
134773 - Entire Scissor Assembly Model 4620 - Without Powered Extension (CE)
(Order P/N 132064 for machines with Serial No. 714053 & Below - Model 4620)
134777 - Entire Scissor Assembly Model 4620 - With Powered Extension (CE)
(Order P/N 132574 for machines with Serial No. 714053 & Below - Model 4620)
1 126329 1 SCISSOR LEVEL, Inside cylinder bottom, A
130254 1 SCISSOR LEVEL, Inside cylinder bottom, B
2 125902 6 SCISSOR ARMS, Outside
3 (Ref.) - MOUNTING, Scissor Stack Assembly
(For components, refer to Figure 6.2-4)
4 130841 2 BUMPER ASSEMBLY, Scissor first level - Front
130840 1 • BUMPER, Scissor Bottom
123713 1 • BOLT, Hex Hd M12-1.25 x 16mm
600426 1 • WASHER, Flat M12
5 103078 AR CLIP, Double G10
122501 AR • SCREW, Machine 3/8”-16 x 5/8” hex washer hd
6 (Ref.) - HARDWARE, Scissor Arm Assembly Connecting
(For components, refer to Figure 6.2-5)
7 120731 1 SCISSOR LEVEL, Inside cylinder top, A
120657 1 SCISSOR LEVEL, Inside cylinder top, B
8 121860 AR BUMPER, Scissor arm
9 123344 1 WELDMENT, Safety bar, A
123324 1 WELDMENT, Safety bar, B
103984 AR • NUT, Hex Lock 5/16”-18 Gr. B
122006 AR • BOLT, Hex head 5/16” -18 x 3 1/4” Gr. 5
10 123354 1 SCISSOR LEVEL, Inside, A
123353 1 SCISSOR LEVEL, Upper Inside, B
11 134749 AR WELDMENT, Cable carrier
(Order P/N 121907 for machines with Serial No. 714053 & Below - Model 4620)
12 130889 2 BUMPER ASSEMBLY, Scissor first level
130840 1 • BUMPER, Scissor Bottom
123713 1 • BOLT, Hex Hd M12-1.25 x 16mm
131953 1 • WASHER, Flat 7/8”
13 (Ref.) - ASSEMBLY, Flashing Light Option
(For components, refer to Figure 6.2-6)
14 (Ref.) - HARDWARE, Lift Cylinder and mounting
(For components, refer to Figure 6-2.8)
