SECTION 6, Page 45SJIII Series - The Conventionals 129919
A 134799 - Entire Scissor Assembly (ANSI/CSA)
(Order P/N 132062 for machines with Serial No. 714053 & Below)
B 135983 - Entire Scissor Assembly (CE)
(Order P/N 132066 for machines with Serial No. 714053 & Below)
1 130254 1 SCISSOR LEVEL, Inside cylinder bottom
2 125902 10 SCISSOR ARMS, Outside
3 (Ref.) - MOUNTING, Scissor Stack Assembly
(For components, refer to Figure 6.2-4)
4 130841 2 BUMPER ASSEMBLY, Scissor first level - Front
130840 1 • BUMPER, Scissor Bottom
123713 1 • BOLT, Hex Hd M12-1.25 x 16mm
600426 1 • WASHER, Flat M12
5 103078 AR CLIP, Double G10
122501 AR • SCREW, Machine 3/8”-16 x 5/8” hex washer hd
6 (Ref.) - HARDWARE, Scissor Arm Assembly Connecting
(For components, refer to Figure 6.2-5)
7 120657 2 SCISSOR LEVEL, Inside cylinder top
8 121860 AR BUMPER, Scissor arm
9 123324 1 WELDMENT, Safety bar
103984 4 • NUT, Lock (hex) 5/16”-18 Gr. B
122006 4 • BOLT, Hex head 5/16”-18 x 3 1/4” Gr. 5
10 132610 1 SCISSOR LEVEL, Upper Inside
11 134749 1 WELDMENT, Cable Carrier
(Order P/N 121907 for machines with Serial No. 714053 & Below)
12 130829 1 SCISSOR LEVEL, Inside cylinder bottom
13 130889 2 BUMPER ASSEMBLY, Scissor first level - Rear
130840 1 • BUMPER, Scissor Bottom
123713 1 • BOLT, Hex Hd M12-1.25 x 16mm
131953 1 • WASHER, Flat 7/8”
14 (Ref.) - ASSEMBLY, Flashing Light Option
(For components, refer to Figure 6.2-6)
15 (Ref.) - HARDWARE, Lift Cylinder and mounting
(For components, refer to Figure 6-2.8)
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.2-3. Scissor Arm Assembly - Model 4632
To Next Page
