SECTION 6, Page 47SJIII Series - The Conventionals 129919
1 120772 1 • PAD, Slider
2 120771 1 • BRACKET, Main Platform Slider (Model 4620, 4632)
134049 1 • BRACKET, Main Platform Slider (Model 4620)
(For Models 4626, order P/N 120771 for Machines with Serial No. 712030 & Below)
3 123430 2 • BUSHING, Fiberglide 3/4”I.D. x 1-1/2”
4 123416 1 • PIN, Main Platform Slider (Model 32XX)
121685 1 • PIN, Main Platform Slider (Model 46XX)
5 103995 1 • WASHER, Flat 1/4”
6 104000 1 • WASHER, Lock 1/4”
7 103892 1 • BOLT, Hex Hd 1/4”-20 x 5/8”
8 121874 1 • COTTER PIN, 1/4” x 1.5”
9 120958 1 • PIN, Ø ¾” x 4” (Scissor level without Cable Carrier Weldment)
121676 1 • PIN, Ø ¾” x 4
1
/
4
” (Scissor level with Cable Carrier Weldment)
10 125470 2 • WELDMENT, Platform Mounting Bracket
11 121856 1 • SPACER, Bottom Roller Pin
12 121604 1 • PIN, Bottom Roller
13 120697 14 • ROLLER, Scissor
14 121605 1 • TUBE, Outside scissor arms Cross Member (Model 32XX)
121672 1 • TUBE, Outside scissor arms Cross Member, (Model 46XX)
Index
No.
Skyjack
Part No.
DescriptionQty.
Figure 6.2-4. Scissor Stack Assembly Mounting AH
